| NO. | Brand | Compatible P/N | Remarks |
| 1 | Cisco | GLC-T | |
| 2 | Alcatel-Lucent | SFP-GIG-T | |
| 3 | Brocade | E1MG-TX | |
| 4 | Cisco Meraki | MA-SFP-1GB-TX | |
| 5 | Huawei | SFP-1000BaseT | |
| 6 | IBM | 00FE333 | |
| 7 | Juniper Networks | JX-SFP-1GE-T | |
| 8 | HPE | JD089A |
The JD089A compatible module is pre-coded with authentic HPE Comware / H3C vendor strings, ensuring native plug-and-play validation without any system CLI errors across:
Enterprise Access Switches: HPE FlexNetwork 5120, 5130, 5140, 5500, 5510, 5520 HI/EI Series
Core & Distribution Switches: HPE FlexNetwork 5800, 5820, 5900, 5930, 5940, 7500 Modular Chassis Series
H3C S5100 / S5500 Series
HP A5120 / A5500 Series
Incompatibility Warning: The JD089A is designed strictly for HPE Comware-based (FlexNetwork/H3C) systems. It is not compatible with HPE ArubaOS-Switch/ProCurve platforms (such as Aruba 2930F or 3810M), which require the J8177D series modules instead.
Primary Application Scenarios of Copper RJ45 SFP Transceiver
The HPE JD089A transceiver is engineered for heavy-duty enterprise switching, core distribution uplinks, and legacy infrastructure integration:
Enterprise Core-to-Access Interconnections: Linking high-performance HPE FlexFabric core switches in server rooms down to local FlexNetwork access-layer switches across patch panels using standard horizontal copper wiring.
Dedicated High-Throughput Server Connections: Converting open SFP slots on modular enterprise line cards into fixed 1G RJ45 interfaces to hook up high-output storage (NAS) clusters or localized compute servers.
Cross-Rack Network Bridging: Directly bridging edge switches to standalone network appliances such as corporate firewalls, hardware load balancers, or security appliances within a 100-meter range.
| Juniper Compatible | JX-SFP-1GE-T | Vendor Name | HYTOPTODEVICE |
| Form Factor | SFP | Data Rate | 1000Mbps |
| Cable Type | Cat 5e/6/6a (UTP) | Max Distance | 100m |
| Interface | RJ-45 | DDM Support | No |
| Protocols | MSA Compliant, IEEE STD 802.3 and 802.3ab | Operation Temperature | 0 to 70°C (32 to 158°F) |
Q1:Does the HPE JD089A support legacy 10M or 100M Ethernet devices?
A1: No. The JD089A is a pure 1000BASE-T transceiver locked to a fixed 1Gbps full-duplex rate. It lacks an SGMII host bus configuration, meaning it cannot down-negotiate its speed. Connected devices on both ends of the cable must be configured for Gigabit Ethernet.
Q2:Can I use the JD089A copper sfp module to connect a 100Mbps Fast Ethernet device?
A2: No. The JD089A copper transceiver is 1000BASE-T, support only fixed 1000 Mbps speeds. it can not connect with 100Mbps device.
Q3:Why won't my JD089A establish a link when inserted into a万兆 (10G) SFP+ slot?
A3: On HPE Comware (5900/5130) switches, SFP+ slots operate at 10Gbps by default. To use this 1G module, you must log into the CLI, enter the system view interface, and manually lock the port speed down to 1000Mbps using the command: speed 1000.
Q4: Does the HPE 1000BASE-T copper SFP support Digital Optical Monitoring (DOM)?
A4: No. It does not support. it is a copper SFP modules. that uses electrical voltage to transfer signals rather than fiber lasers, meaning optical diagnostic telemetry does not apply.
Q5: Is this transceiver hot-swappable?
A5: Yes. it is pluggable transceiver. the module features a hot-pluggable architecture. You can insert or extract it from active SFP slots without restarting the switch or interrupting neighboring active data lines.
Why Network Engineers Choose HYTOPTODEVICE
HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.
100% MSA-compliant modules with Cisco, Huawei,Dell,Juniper, and Arista compatibility
ISO 9001:2015 certified manufacturing facility in Shenzhen
Average lead time of 3–5 business days with DHL/FedEx express options
Dedicated pre-sales engineering support for custom configurations
Actual hardware,actual switches,actual results.we publish compatibility test video,eliminate compatibility anxiety. you can watch before you buy.
We can provide inspection and shipping videos to make you feel as if you are right here with the product.
"We replaced 200 Cisco-branded SFPs with HYTOPTODEVICE equivalents across our spine layer — zero compatibility issues, 40% cost reduction."— Network Architect, Tier-2 ISP, Germany
Quality Certification & Compliance：
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final inspection, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
ISO 9001: Certified quality management and production consistency.
CE & FCC: Fully compliant for seamless Global Market Access.
RoHS: Committed to environmental responsibility and hazardous material control.
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
